X27 ColorVision Osprey Day/Night Ultra LLL True Color night vision military Imaging system Available in the stabilized Z55 airborne unmanned UAV DRONE configuration
The digital X27 ColorVision (R) reconnaissance LLL (Low Light Level) true Color night vision VIS-NIR sensor
is a technological breakthrough in night vision technology.
High performance, low noise, high sensitivity & outstanding true LLL color imagery are just a few features offered by the system.
The SWaP UHD Color Night Vision sensor can be
integrated into night vision sights, scopes, monoculars, binoculars, drivers aid, UAV, UAS, unmanned
and a wide array of defense, homeland security, border, ground,
mobile, marine, airborne, military, wildlife, documentary, specialty combat camera photography, Astro/aerial/airborne/space
remote imaging, aurora borealis, security and surveillance applications.
The advanced ColorVision(R) system incorporates highly sensitive BSTFA Broad Spectrum Thin Film Array photodetector along with powerful
proprietary MDIS MultiLayer Digiscan Image Sequencing – real time HD video processing.
Z55 advanced multi sensor uav with X27 color night vision / EO-IR
General
Max Takeoff Weight:
Empty Weight:
Operating Temp:
Max Speed:
Voltage:
IP Rating:
55 pounds
18.2 pounds
-20C to 45C
60 mph
12S (44.4V)
IPX7
Dimensions
Unfolded Diameter:
Unfolded Height:
Folded Diameter:
Folded Height:
2000 mm
625 mm
670 mm
625 mm
Propulsion
Equivalent KV:
Propeller:
Maximum Thrust:
Maximum RPM:
100
30×10
123 pounds
3600
Flight Controller
Autopilot:
Flight Modes:
Supported Radio:
Supported GNSS:
Cube Orange
Manual, Altitude, Loiter, Mission, RTL
Herelink, Futaba, FrSky, SBus
Dual Here 3 GPS (RTK if requested)
Misc
Payload Rail:
External Power:
External COM:
External Video:
FPV Video Feed:
12mm OD, Center-to-Center 165 mm
5V, 12V, 44.4V options
SBus, Serial, CAN, PWM, I2C
X27 / thermal / visual
High Definition FPV (1080P)
Compact folding wing system, rugged advanced heavy lift UAV, NDAA compliant available, includes X27 color broadband NV and Thermal IR imaging channels
Airborne drone x27 Color night vision footage (L) side by side compared to standard camera (R)
The System Detects battle infrared lasers / illuminators and can also see the JATC SeeSpot 1064 Designator IR laser in day and night.
