Detector type: 17μm, Uncooled
Refresh rate: 50 Hz
Resolution: 384 x 288
FOV: 7.4 ° × 5.6° (H x V)
SPI Stinger T384-50-SS
THERMAL WEAPON SIGHTS | PART #T384-50-SS
CHARACTERISTICS
PACKAGE INCLUDES
- Two Lithium CR123A batteries
EXPORT RESTRICTIONS
Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.
DESCRIPTION AND FEATURES
The SPI Stinger-Micro is a compact thermal imaging scopes developed for 24 hours operation under any weather and environmental conditions. Two modifications of objective lenses allows to choose perfect unit for your needs where 35 mm lens designed for short range shooting, while 50 mm lens model will be great for medium range missions. Powered with two CR123 batteries the SPI Stinger-Micro gives up to 5 hours of continues work. An external 5V power bank (battery pack) can be easily connected via a USB connector for a significant increase of operating time
- Lightweight and compact design
- Easy to operate device
- High resolution 1024×768 display
- Waterproof
- Powered by two standard CR123A batteries
- External power supply via micro USB
SPECIFICATIONS
| Operating Temperature Range | -25°C to +50°C (-4°F to +122°F) |
| Close-up range | 5 m |
| Video / photo format | AVI / JPG |
| On-board memory | 128 MB (32 GB optional) |
| Degree of protection | IP67 |
| Shock and vibration | 1200 g/ms |
| Storage temperature range | -40°C to +70°C (-40°F to +158°F) |
| Detector type | 17μm, Uncooled |
| Resolution | 384 x 288 |
| Lens system | 50 mm; F/1.1 |
| Optical magnification | 2.7x |
| Field of view (H × X) | 7.4 ° × 5.6° (H x V) |
| Digital zoom | 2x, 4x |
| Diopter adjustment range | -5 to +5 dpt |
| Eye relief | 60 m |
| Display | OLED (1024×768) |
| Battery Type | Two CR123 |
| Battery Life (Operating) | Up to 5 hr |
| External power supply | 5V USB |
| Power supply | 3.6~7.2V |
| Weight | 0.41 kg (0.90 lbs) |
| Overall Dimensions | 193 x 65 x 67 mm (7.5 × 2.8 × 2.6 in) |
