Image Intensifier Tube: Gen 3 “Level 2”
Magnification: 5.6x
Lens System: 145 mm; F/1.8
FOV: 7°
SPI BLACKBIRD 6X-NGEN3-B2
NIGHT VISION BINOCULARS | PART #NGEN3-B2
CHARACTERISTICS
PACKAGE INCLUDES
- SPI SPARK850 Long Range Infrared Illuminator with Mount
- Dovetail to Weaver Transfer Piece
- Rechargeable Battery
- Charger
- Operators Manual
- Lens Tissue
- One Lithium Battery CR123A,
Soft Carrying Case
EXPORT RESTRICTIONS
Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.
DESCRIPTION AND FEATURES
The SPI Blackbird-LE night vision bi-ocular is the perfect tool for mid-range and long-range observation. The Blackbird-LE is compatible with a range of professional high quality objective lenses to match all users’ requirements currently available in three configurations – 5x, 8x, and 10x magnification. The Blackbird-LE is a professional night vision device favored by law enforcement and military units due to its unmatched performance, even in extreme temperatures and challenging weather conditions such as rain or excessive humidity. The device can be outfitted with either a Gen 2+ or Gen 3 high-performance image intensifier (II) tube, which can be repaired or upgraded easily. The bright light shut-off feature ensures that the high-quality photocathode tube is protected. The Blackbird-LE is also equipped with Automatic Brightness Control (ABC), which adjusts the image brightness automatically, providing the highest possible image quality even in changing light conditions. Blackbird-LE is supplied with two AA batteries and its operating time is up to 40 hours of continuous use.
- 5x, 8x or 10x magnification
- Lightweight rugged design
- Waterproof
- Auto brightness control
- Ergonomic, simple, easy to operate controls
SPECIFICATIONS
Image Intensifier Tube
Gen 3 "Level 2"
Resolution
64-72 lp/mm
Field of view cleanness by zone
Gen 3 IIT 3NL2 is the second best quality offered by SPI with very limited number of spots in Zone 1.
Magnification
5.6x
Lens System
145 mm; F/1.8
FOV
7°
Focus Range
25m to Infinity
Diopter Adjustment
-6 to +2 dpt
Led Indicators
Low battery; IR On; Excessive light conditions
Automatic Brightness Control
Yes
Infrared Illuminator
Detachable long-range IR illuminator
Bright Light Cut-Off
Yes
Automatic Shut-Off System
Yes
Battery Type
2 AA Alkaline or 1 Lithium (BA-5567/U)
Battery Life (Operating)
Up to 60 hours at 20°C
Operating Temperature Range
-40°C to +50°C (-40°F to +122°F)
Storage Temperature Range
-50°C to +50°C (-58°F to +122°F)
Weight
1.02 kg (2.25 lbs)
Overall Dimensions
282 × 152 × 96 mm ( 11.1 × 6.0 × 3.8 in)
Package Includes
Night Vision Binocular, SPARK850 Detachable Long-Range IR Illuminator Lens Cloth, Soft Carrying Case
